3D Modeling Services

Creation of an accurate existing conditions 3D model based on site verification scans. Coverage included: Walls, floors, ceilings, major structural elements, openings (doors/windows), existing electrical boxes and plumbing, drop ceilings and bulkheads. This model is suitable for as-built documentation and shop drawings reference, ensuring clarity in trade-specific modeling and promoting clash awareness (not full coordination).

Plans and elevations are dimensioned for fabrication reference, incorporating existing conditions 3D models and site verification scans for accuracy. Formats include PDF, DWG, DXF, and RVT, ensuring trade-specific modeling is accommodated.

Tolerance is clearly defined (e.g. ±1–5 mm depending on scan quality) based on visible and accessible existing conditions 3D model only, utilizing site verification scans for accuracy in trade-specific modeling.

DXF, Revit, DWG, and PDF formats can be utilized to create existing conditions 3D models, which are essential for site verification scans and trade-specific modeling.
